Elliptical Mirror 12.7mm Minor Axis Uncoated

×
Stock #32-270 5-7 Days
×
Quantity Selector - Use the plus and minus buttons to adjust the quantity. +
NT$2,573
Qty 1-5
NT$2,573
Qty 6+
NT$2,065
Volume Pricing
Request Quote
下載產品資料

Specifications

概況

Note:
Flatness specification is Peak to Valley
Type:
Flat Mirror

物理和機械特性

Minor Axis (mm):
12.70
Major Axis (mm):
17.96
Dimensional Tolerance (mm):
±0.38
Dimensional Tolerance (inches):
±0.015
Clear Aperture CA (mm):
11.43 (Minor Axis)
16.15 (Major Axis)
Thickness (mm):
3.81
Thickness Tolerance (inches):
±0.020
Thickness Tolerance (mm):
±0.51

光學特性

Surface Flatness (P-V):
λ/8
Substrate: Many glass manufacturers offer the same material characteristics under different trade names. Learn More
Surface Quality:
60-40
Coating:
Uncoated
Coating Type:
Uncoated

Regulatory Compliance

RoHS 2015:
Reach 211:
Certificate of Conformance:

產品概覽

See Figure B in Technical Information tab for dimensional diagram.
  • 方向為45°時呈現圓形
  • 非常適用於變更光線方向
  • 提供多種尺寸與鍍膜

我們的TECHSPEC® λ/8精密橢圓形平面反射鏡非常適用於研究與天文學應用。由於這些反射鏡具有延長的長軸,因此適合以精確的角度將光線折彎及翻轉(具有極小的光波畸變)。我們提供多種尺寸與鍍膜選項,以完美適合諸多應用。
