Model Number:

MR-15-30-DVIS-25x25D

Diameter (mm):

15.00

Housing Diameter (mm):

45

Coating:

Dielectric Mirror (400-750nm)

Coating Specification:

R_avg ≥98% @ 400 - 750nm

Surface Quality:

60-40

Mechanical Tilt (°):

±25

Repeatability (μrad):

30 - 100 RMS

Storage Temperature (°C):

-40 to +85

Operating Temperature (°C):

0 to +40

Operating System:

Windows® 10

Power Requirement:

15 - 28 VDC

Power Supply:

Power Supply Required and Sold Separately:
USA: #14-576
Europe: #14-576
Japan: Not Available
Korea: Not Available
China: #14-576

Note:

Do not connect or disconnect the mirror head while the base unit is connected to power as this will damage the mirror driver.

Scan Angle (°):

±25 (Mechanical)
±50 (Optical)

Step Response 0.1° (ms):

2

Step Response 20° (ms):

12

15mm Dia. Mirror, VIS Dielectric, Optotune Dual Axis Fast Steering Mirror with Position Feedback
